Wall - Mounted Convectors

Wall - Mounted Convectors

* The heating capacities specified in the table are for 1000 mm length.
 * Inlet water temperature 75 ° C
* Outlet water temperature 65 ° C
* Indoor temperature 20 ° C
Visit the MINIB Site for a change of parameters (length, inlet and outlet temperature, indoor temperature) and a quick calculation of your choice.

MODEL

WİDHT (mm)

HEİGHT (mm)

LENGHT (mm)

HEATİNG OUTPUT  (W/m)

NUF1

115

178

900-2000

516

NUF2

115

348

900-2000

655

NPF1

150

178

900-2000

665

NPF2

150

348

900-2000

1047

NMF1

195

178

900-2000

1031

NWF2

220

348

900-2000

1539

NWF3

220

518

900-2000

1776

NKF1

150

178

900-2000

2095

NKF2

150

348

900-2000

2223

NKF PTG

150

256

1000-2000

1289

NCA

156

469

900-2000

3613

NCA 4P

156

469

900-2000

1526

* High convectionnaturalandforcedefficiency.

* Responsetimesareshort.

* Theycontinuetoheatwhenthe fan is off.

* Theyhavelowelectricityconsumption.

* Availablewithsafe 12 V DC supply.

* Differentcoloroptionsareavailable.
